SB Acoustics SB29RDCN-C000-4 Ring Dome Tweeter with Neodymium Magnet

This tweeter features a proprietary fabric ring dome with a large roll surround. Stabilizing the center of the dome greatly reduces distortion and brings the acoustic center of the tweeter back to the voice coil, with the added benefit of increased sensitivity. The tweeter has a chambered back designed to provide a lower resonance frequency and reduce back wave reflections from the dome. A copper cap is used on the pole piece.

72 mm flange diameter (2.83")
55 mm cut out hole size (2.16")
3 mm flange thickness (0.118")
28 mm depth (1.1")

Impedance 4 ohm
DC resistance 3.0 ohm
V.C. inductance 0.05 mH
Effective cone area 9.6 cm2
V.C. diameter 29 mm
VC height 2.0
Air gap 2.5
Linear excursion ±0.5 mm
Moving mass incl. air 0.45 g
Free air resonance Fs 580 Hz
Sensitivity 2.83V/1M 94 dB
Qms 0.9
Qes 0.54
Qts 0.34
Power 100 W
Magnet flux density 1.2 T
Magnet weight 0.31 kg
Net weight 0.17 kg
