Recently in New to Madisound Category
ZA5 Autosound 2-Way
We are pleased to announce a new addition to the Zaph Audio ZA5 Family; the ZA5 Autosound 2-Way Kit.
This kit utilizes the ZA14W08 woofer and the Seas Prestige 27TAFNC/G (H1397) 1" aluminum dome tweeter. We professionally assemble the crossover on a compact circuit board for easy installation.
You can learn more about the ZA5 family of kits on the Zaph Audio website, and purchase any of the designs by visiting the Madisound ZA5 Store Page.
We are pleased to announce a new addition to the Zaph Audio ZA5 Family; the ZA5 Autosound 2-Way Kit.
This kit utilizes the ZA14W08 woofer and the Seas Prestige 27TAFNC/G (H1397) 1" aluminum dome tweeter. We professionally assemble the crossover on a compact circuit board for easy installation.
You can learn more about the ZA5 family of kits on the Zaph Audio website, and purchase any of the designs by visiting the Madisound ZA5 Store Page.
Madisound Gift Certificates are available for your last minute holiday shopping.
Delivery by Christmas Eve or by email as a PDF file.
Free shipping!
Good for any Madisound product or service and available in many denominations.
Buy your Madisound Gift Certificates now!
Delivery by Christmas Eve or by email as a PDF file.
Free shipping!
Good for any Madisound product or service and available in many denominations.
Buy your Madisound Gift Certificates now!
RB3-Kit, the 3rd Vifa "Recession Buster Kit MK3"
The Madisound "Recession Buster Kit" is back and better than ever!
The RB3 is a 7" 2-way using Vifa drivers and is available as a parts only kit or complete with furniture grade cabinets.
Tweeter:
Vifa D27TG45-06 1" Soft Dome Tweeter
Woofer:
Vifa PL18WO09-08 7" Paper Cone Woofer
Complete detailed information is available here.
The Madisound "Recession Buster Kit" is back and better than ever!
The RB3 is a 7" 2-way using Vifa drivers and is available as a parts only kit or complete with furniture grade cabinets.
Tweeter:
Vifa D27TG45-06 1" Soft Dome Tweeter
Woofer:
Vifa PL18WO09-08 7" Paper Cone Woofer
Complete detailed information is available here.
Vifa NE265W, 10" Woofer, 4 ohm
The first driver from the new Vifa NE line has arrived!
The Vifa NE product line have cutting-edge transducer technology with a stylish design. The woofers in this product line feature an innovative aluminum basket design which minimizes acoustic reflections inside the driver. The basket is both a heat sink and a neodymium motor. The cone and dust cap are coated natural wood fiber material. The cone has pentacone technology for improved performance.
Other Vife NE drivers will soon be available. For detailed specs...
Vifa NE Tweeters
We are proud to introduce the Zaph Audio ZA5 family of speaker kits.
This expansive offering of kits is based around the new Zaph ZA14W08 woofer and Vifa DQ25SC16-04 tweeter. We are selling the kits to include the drivers for each design along with professionally assembled crossovers. You may also choose to purchase an optional accessories package with each kit. Both the kits and accessories packages include a 10% discount on all parts.
Consider the ZA5 kits for both stereo listening and surround sound enjoyment. Combine your choice of ZA5 designs to accomplish nearly any project objective.
Here are your options:
- ZA5.2 TM 2-Way
- ZA5.3 MTM
- ZA5.3c Center Channel
- ZA5.3t TMM Tower
- ZA5.5 Tall Tower w/ 4 woofers & 1 tweeter in each cabinet!
- All kits available in singles, pairs, or whatever you require.
The SB Acoustics SB12.3 designed by Zaph Audio.
This beast of a kit delivers everything you could desire from a floor standing full range speaker system. We are excited to make it available to you!
The SB12.3 is a four driver sealed box 3-Way, utilizing a 12" woofer and two 5" mids flanking a ring dome tweeter in MTM formation.
Each SB12.3 Kit Includes:
- (2) SB34NRX75-6 12" Woofers
- (4) SB15NRXC30-8 5" Midrange Drivers
- (2) SB29RDC-C000-4 Ring Dome Tweeters
- (2) Professionally Assembled Crossovers
Enjoy!
These drivers feature coated fiberglass cones and well ventilated cast aluminum frames. Their frequency response is smooth and extended with a very controlled roll off.
They are manufactured in Denmark, and posses the high quality sound reproduction and build that we have all come to expect from Scan-Speak.
- 10F/4424G00 - 4" Midrange with neodymium magnet system
- 15W/8434G00 - 5.25" Midwoofer
- 18W/8434G00 - 6.5" Midwoofer
SB Acoustics SW26DAC76-4 Shallow 10" Subwoofer
- Unique dual mirrored aluminum cone
- Very shallow profile (could be used in-wall)
- 3" diameter voice coil
- Long throw
- Cast frame
- 4 ohm
Madisound is now stocking the ClarityCap in 2.7 mfd for each cap series.
Fountek RM6K in Cherry - Assembled Pair - $450
This is a 6.5" 2-way using a ribbon tweeter and aluminum cone woofer.
We are offering 10 fully assembled pairs at this special price. The fit and finish of the cabinets are top notch, and no assembly is required!
$450 will get you one fully assembled stereo pair including:
- Fountek NeoCd3.0 Ribbon Tweeters
- Fountek FW168 6.5" Aluminum Cone Woofers
- High Quality Cherry Cabinets with removable grill covers
Seas Prestige 8" Woofer CD22RN4X H1192
Double treated, hard paper cone designed to be very stiff without losing the damping capability, together with a natural rubber surround produce a well behaved roll off characteristic and reduce potential resonance problems.
Large magnet system with bumped back plate together with a long 4-layer voice coil gives long linear excursion. The magnet system has a T-shaped cross section of the pole piece for low modulation distortion.
Extremely stiff and stable injection moulded metal basket keeps the critical components in perfect alignment. Large windows in the basket both above and below the spider reduce sound refl exion, air flow noise and cavity resonances.
Zaph Audio ZA14W08 5" Mid/Woofer
Having already cemented himself into DIY speaker building lore with comprehensive driver testing and review, as well as many highly regarded (and very well documented) designs and kits..... Zaph is at it again.
Madisound is pleased to introduce a new driver to our lineup, the Zaph Audio ZA14W08 5" Mid/Woofer.
We are confident that you will see what we do in this highly attractive driver that hits the sweet spot in both performance and price.
Please stay tuned for a full line of kits based around the exciting new Zaph 5" Aluminum Cone Mid/Woofer!
Update: This kit is no longer available.
RBR-KIT, "Recession Buster Reference" Kit
Following the overwhelming success of the Recession Buster Kit 1 & 2, Madisound is pleased to introduce the limited edition Recession Buster Reference Kit.
This 5.5" 2-way speaker kit utilizes a Scan-Speak Revelator woofer and SB Acoustics Ring Dome tweeter.
Along with Clearwave Loudspeaker Design, we bring you an unprecedented value in the form of a premium speaker kit. Never before, and perhaps never again, will we be able to offer this high level of performance at such an attractive price. Quantity is limited.
- RBR-KIT is priced well under the cost of the two woofers - what a great deal!
- Scan-Speak Revelator 15S/8531K-01 5.5" woofers - the best of the best!
- SB Acoustics SB29RDC-C000-4 Ring Dome tweeters - cutting edge technology!
- Fully Documented Design - sweet, sweet sound!
- Professionally Assembled Crossovers - premium parts throughout!
- Optional Accessories Package Available - build it ported or sealed!
Fostex FW168HR, 6.5" Wideband Woofer
- ø145mm large ferrite magnet and 8mm top plate are employed. Besides, the copper cap is adapted onto the pole piece to reduce the magnetostriction.
- HR shape cone diaphragm is employed to realize the weight saving and stiffness property.
- The state-of-the-art hybrid material is offered to the diaphragm. Its ideal internal loss and stiffness bring the propagation velocity similar to the near-metal diaphragm
- UDR tangential surround & spider are equipped to realize the less anti-resonance and superior amplitude characteristic.
- The foamed rubber is chosen for the surround material. It has the lower density, lighter weight and higher internal loss characteristic than the conventional rubber and the foamed rubber surround has the low young's modulus and less eigentone.
SB Acoustics SB29RDCN-C000-4 Neo Magnet, Ring Dome
This tweeter features a proprietary fabric ring dome with a large roll surround. Stabilizing the center of the dome greatly reduces distortion and brings the acoustic center of the tweeter back to the voice coil, with the added benefit of increased sensitivity. The tweeter has a chambered back designed to provide a lower resonance frequency and reduce back wave reflections from the dome. A copper cap is used on the pole piece.
This tweeter features a proprietary fabric ring dome with a large roll surround. Stabilizing the center of the dome greatly reduces distortion and brings the acoustic center of the tweeter back to the voice coil, with the added benefit of increased sensitivity. The tweeter has a chambered back designed to provide a lower resonance frequency and reduce back wave reflections from the dome. A copper cap is used on the pole piece.
SB Acoustics SW26DAC76-8 Shallow 10" Subwoofer
- Unique dual mirrored aluminum cone
- Very shallow profile (could be used in-wall)
- 3" diameter voice coil
- Long throw
- Cast frame
Peerless 835017, 12" XXLS Subwoofers, Aluminum Cone
- 4 ohm impedance
- Black aluminum cone
- Large roll rubber surround
- Low distortion motor
- 50mm voice coil diameter
- 12.5mm linear excursion (x-max peak)
- Suitable for home or autosound systems
Peerless 835016, 10" XXLS Subwoofers, Aluminum Cone, 4 ohm
Kester Silver Solder, 60 grams
- 96.5 percent Tin (Sn)
- 3.0 percent Silver (AG)
- 0.5 percent Copper (Cu)
- Flux Cored Wire
- Lead free (RoHS Compliant)
- No-Clean Flux
- 0.031" diameter (8mm)
Seas Prestige A26RE4 (H1411)
The A26RE4 is the modern version of the once popular 25F-EW woofer used in the Dynaco A25 system. Seas has stopped using the old 25cm frame and now uses the 26cm frame. This new woofer will not fit in the Dynaco A25 speaker anymore.
This classic paper cone has a wonderful roll off at 2000Hz. This is one of the only 10" drivers we know of that could be used in a 2-way by letting the woofer run full range without a crossover. I have heard this woofer with the Seas H1189 Tweeters and it had a magical retro sound to it.
- Neoprene glue
- 2 fluid oz in squeeze tube
- Black
- Use to glue speaker surrounds
- Works for foam or rubber surrounds
Madisound is pleased to announce that we now stock the ESA Range of ClarityCap capacitors.
SB Acoustics Subwoofers Kits with 10" or 12" Drivers, Cabinets, and a Sub Amp
We combined the SB Acoustics 10" or 12" woofer, our Keiga 300 watt amp, and a high quality furniture grade cabinet in an easy to build Subwoofers kit. Everything you need to construct a finished Subwoofers is included.
The first RB-Kits was such a success, we decided to create a new version.
The new kit will have the same woofer and a new Tweeters. Each RB2-Kits includes:
(2) Vifa BC25TG15-04, 1" Textile Dome Tweeters
(2) Vifa TC14WG49-08, 5.5" Coated Paper Cone Wooferss
(2) Assembled Crossovers
Full details will soon be posted at RB2-Kits, the 2nd Vifa "Recession Buster Kits"
Madsound is pleased to announce new content created by our staff!
Restoring Vintage Loudspeakers by Josh Biernbaum
"We at Madisound are often asked about what is the best way to upgrade older or vintage loudspeakers. In fact there are many ways to improve on sound, whether perceived as too dull, too bright or boomy, or not enough dynamics, for some examples. Loudspeakers vary greatly in build quality, from the drive units, cabinets, and wiring to the internal electrical parts. Rather than spending thousands of dollars to achieve results, we will suggest some simpler and less expensive solutions involving some straightforward modifications that almost anyone can make. The purpose of this guide is not to address loudspeaker design, or crossover theory, but to offer inexpensive tweaks that can improve the presentation of your speakers..."
Read the rest: Restoring Vintage Loudspeakers.
N-Compass Router Jig
The N-Compass router jig is a precision compass tool designed for cutting accurate circles and arcs. It has the ability to cut a range of diameters from very small radii to very large radii, simply and hassle free.
The router attaches to the compass jig using its base plate guide rod holes. The cutting radius is set using the router base plate's guide rod locking pins which can then be finely tuned using a Vernier micro-adjuster.
How many different ways are there to cut a circle? Too many, and most of them are time-consuming, require quite a few steps, and the sacrifice of a substantial amount of material. Even the most obvious non-router technique (rough-cutting a circle with a jig saw and then using a jig with a belt or disk sander to true-up the edges) is surpassed by using circle template with a pattern-following or flush-trimming bit, so why not just cut the primary circle with the router and get that crisp, finished edge in one step without all the hassle? The answer before the advent of the N-Compass would have likely been "because by the time I waste the time and a piece of wood to make the trammel arm I could do it more efficiently another way," but not now. It's not uncommon to have the N-Compass installed on the router and set to length in well under a minute, and without dulling your bits and blades!
We also carry the excellent router guides by Jasper Tools:
The N-Compass router jig is a precision compass tool designed for cutting accurate circles and arcs. It has the ability to cut a range of diameters from very small radii to very large radii, simply and hassle free.The router attaches to the compass jig using its base plate guide rod holes. The cutting radius is set using the router base plate's guide rod locking pins which can then be finely tuned using a Vernier micro-adjuster.
How many different ways are there to cut a circle? Too many, and most of them are time-consuming, require quite a few steps, and the sacrifice of a substantial amount of material. Even the most obvious non-router technique (rough-cutting a circle with a jig saw and then using a jig with a belt or disk sander to true-up the edges) is surpassed by using circle template with a pattern-following or flush-trimming bit, so why not just cut the primary circle with the router and get that crisp, finished edge in one step without all the hassle? The answer before the advent of the N-Compass would have likely been "because by the time I waste the time and a piece of wood to make the trammel arm I could do it more efficiently another way," but not now. It's not uncommon to have the N-Compass installed on the router and set to length in well under a minute, and without dulling your bits and blades!
We also carry the excellent router guides by Jasper Tools:
- Jasper 400 Perfect Circle Guide for Plunge Routers
- Jasper 200 Perfect Circle Guide for Plunge Routers
RB-Kits, the Vifa "Recession Buster Kits", Pair
Madisound is excited to bring you the "Recession Buster Kits". This 2-Way kit offers a premium, yet incredibly affordable system using Vifa drivers and custom crossovers.
Both the woofer and Tweeters were produced in Denmark, and the crossovers are fully assembled for easy hook up and installation. Each Kits Includes:
Madisound is excited to bring you the "Recession Buster Kits". This 2-Way kit offers a premium, yet incredibly affordable system using Vifa drivers and custom crossovers.
Both the woofer and Tweeters were produced in Denmark, and the crossovers are fully assembled for easy hook up and installation. Each Kits Includes:
- (2) Vifa D25AG77-06 1" Black Aluminum Dome Tweeters
- (2) Vifa TC14WG49-08 5.5" Coated Paper Cone Wooferss
- (2) Assembled Crossovers
New Scan-Speak Illuminator Tweeters: Soft Dome
Scan-Speak Illuminator D3004/6620-01 Tweeters in silver
Scan-Speak Illuminator D3004/6620-00 Tweeters in black
The Illuminator Tweeters continue on with the heritage of the renowned Revelator D29. The large-roll surround and textile dome diaphragm provide a flat frequency response to above 30KHz with outstanding off-axis dispersion. The face plates are die cast in aluminum for a beautiful look with maximum mechanical stability. Tymphany's unique AirCirc Magnet System - named for the way it optimizes air flow within the chamber - rearranges the traditional magnet structure from a single magnet to an open magnetic circuit comprised of six separate neodymium slugs. This, in combination with the chamber, results in the elimination of the reflections and resonances that compromise the performance of traditional motors. The D3004 gives engineers improved control over critical midrange performance, for superb vocal rendition and excellent imaging at all listening locations.
Driver Highlights: 1" soft dome, AirCirc Magnet System, Rubber painted aluminium die casted faceplate
Scan-Speak Illuminator D3004/6620-01 Tweeters in silver
Scan-Speak Illuminator D3004/6620-00 Tweeters in black
The Illuminator Tweeters continue on with the heritage of the renowned Revelator D29. The large-roll surround and textile dome diaphragm provide a flat frequency response to above 30KHz with outstanding off-axis dispersion. The face plates are die cast in aluminum for a beautiful look with maximum mechanical stability. Tymphany's unique AirCirc Magnet System - named for the way it optimizes air flow within the chamber - rearranges the traditional magnet structure from a single magnet to an open magnetic circuit comprised of six separate neodymium slugs. This, in combination with the chamber, results in the elimination of the reflections and resonances that compromise the performance of traditional motors. The D3004 gives engineers improved control over critical midrange performance, for superb vocal rendition and excellent imaging at all listening locations.
Driver Highlights: 1" soft dome, AirCirc Magnet System, Rubber painted aluminium die casted faceplate
New Scan-Speak Illuminator Tweeters: Ring Radiators
Scan-Speak Illuminator R3004/6620-00 Ring Radiator Tweeters in black
Scan-Speak Illuminator R3004/6620-01 Ring Radiator Tweeters in silver
Scan-Speak Illuminator R3004/6620-00 Ring Radiator Tweeters in black
Scan-Speak Illuminator R3004/6620-01 Ring Radiator Tweeters in silver
The Illuminator Tweeters continue on with the heritage of the renowned Revelator D29. The large-roll surround and textile dome diaphragm provide a flat frequency response to above 30KHz with outstanding off-axis dispersion. The face plates are die cast in aluminum for a beautiful look with maximum mechanical stability. R3004 builds on the experience of the one-inch R29 ring radiator, resulting in low resonance frequency, superb vocal rendition and excellent imaging at all listening locations. Tymphany's unique AirCirc Magnet System -- named for the way it optimizes air flow within the chamber - rearranges the traditional magnet structure from a single magnet to an open magnetic circuit comprised of six separate neodymium slugs. This, in combination with the chamber, results in the elimination of the reflections and resonances that compromise the performance of traditional motors.
Driver Highlights: 1" Ring Radiator, AirCirc Magnet System, Rubber painted aluminum die casted faceplate
Vifa XT18WO09-08, 6.5" Woofers
Wood-fibre cone and dustcap, multi-roll surround, low distortion magnet system, airflow optimized chassis
With a high density, low resonance, airflow-optimized chassis it allows maximum airflow under the spider. The result is much lower compression of air in the magnet system, which has also been optimized to reduce distortion. A Wood-fibre cone and phase integrated dust cap is a new technology that strives for the optimum sound quality. Vifa has always been known for searching for the best sound and will only adapt the best materials to achieve this. Low Resonance Multi-roll Surround (LRMS) is another design element used in this series to reduce resonance.
Wood-fibre cone and dustcap, multi-roll surround, low distortion magnet system, airflow optimized chassis
With a high density, low resonance, airflow-optimized chassis it allows maximum airflow under the spider. The result is much lower compression of air in the magnet system, which has also been optimized to reduce distortion. A Wood-fibre cone and phase integrated dust cap is a new technology that strives for the optimum sound quality. Vifa has always been known for searching for the best sound and will only adapt the best materials to achieve this. Low Resonance Multi-roll Surround (LRMS) is another design element used in this series to reduce resonance.
Eton 7-300/A8 Symphony, 7" Mid/Bass with Phase Plug
- 7" 3-layer Hexacone sandwich diaphragm mid/bass, rigid and stiff
- Excellent as midrange in multiple-way system, 2-way system or MTM
- Phase Plug
- Aluminum former
- Good for vented box
- Frequency 40Hz-5kHz
- Flange 175mm
- Cut-out 152mm
- Depth 80mm
Eton 5-300/A8 Symphony 5" Mid/Bass with Phase Plug
- 5" 3-layer Hexacone sandwich diaphragm mid/bass, rigid and stiff
- Phase Plug
- Excellent as midrange in multiple-way system, 2-way system or MTM
- Aluminum former
- Frequency 55Hz-4kHz
- Flange 145mm
- Cut-out 118mm
- Depth 64mm
Eton 5-200/A8 Symphony, 5" Mid/Bass with Aluminum Former
- 5" 3-layer Hexacone sandwich diaphragm mid/bass, rigid and stiff
- Excellent as midrange in multiple-way system, 2-way system or MTM
- Aluminum former
- Frequency 50Hz-4kHz
- Flange 145mm
- Cut-out 118mm
- Depth 64mm
Eton 26HD1/A8 Symphony Magnesium Dome Tweeters
- Magnesium diaphragm sandwiched between ceramic layers
- Sandwich design provides stiffness and high damping factor (magnesium)
- All the detail without any sharpness
- Neodymium magnet
- Protective diffuser
- Non-reflective rear chamber
- Aluminum former
Scan-Speak Illuminator D2004/6020-00 Tweeters
The face plates are die cast in aluminum for a beautiful look with maximum mechanical stability.
- 3/4" soft dome
- Ring neodymium magnet
- Aluminum face plate and housing
- Protective grill
The face plates are die cast in aluminum for a beautiful look with maximum mechanical stability.
The back chamber is die cast in aluminum and designed with a contoured shape that functions as a heat sink in high power applications.
Scan-Speak Illuminator 15W/8741T-00 5" Woofers
- Under hung voice coil
- Neodymium magnet
- Exceptionally long linear excursion
- Paper cone
- 8 ohm
Fountek Kits 6.5" Ribbon Monitor Kits - RM6K
Madisound is pleased to bring you our first all Fountek Speaker Kits. The Tweeters is the highly regarded NeoCd3.0 paired with the all new FW168 6.5" aluminum cone woofer.
Fountek continues to impress us with their product offerings. We logged many hours on these with a wide range of music. They performed extremely well in all regards. So well in fact, we may not be able to pry them away from the employee who is now using them as desk monitors.
This kit is available complete with cabinets, or parts only. You choose!
With Cabinets
Parts Only
Madisound is pleased to bring you our first all Fountek Speaker Kits. The Tweeters is the highly regarded NeoCd3.0 paired with the all new FW168 6.5" aluminum cone woofer.
Fountek continues to impress us with their product offerings. We logged many hours on these with a wide range of music. They performed extremely well in all regards. So well in fact, we may not be able to pry them away from the employee who is now using them as desk monitors.
This kit is available complete with cabinets, or parts only. You choose!
With Cabinets
Parts Only
Scan-Speak Illuminator D3004/602010 Tweeters
- 1" soft dome
- Deep chamber
- Ring neodymium magnet
- Aluminum face plate and chamber
- Protective grill
- 61.9mm (2.44") diameter flange with 55.4mm (2.18") depth
The face plates are die cast in aluminum for a beautiful look with maximum mechanical stability.
The back chamber is die cast in aluminum and designed with a contoured shape that functions as a heat sink in high power applications.
Scan-Speak Illuminator D3004/602000 Tweeters
- 1" soft dome
- shallow chamber
- ring neodymium magnet
- aluminum face plate and chamber
- protective grill
- 61.9mm (2.44") diameter flange with 21.5mm (.85") depth
The face plates are die cast in aluminum for a beautiful look with maximum mechanical stability.
D3004/602000 is optimized to offer small package sizes that can fit into tight spaces such as compact cabinets and automotive trim pieces.
The back chamber is die cast in aluminum and designed with a contoured shape that functions as a heat sink in high power applications.
18WU/8741T-00, 7" Woofers, 8 ohm
- Under hung voice coil
- Neodymium magnet
- Exceptionally long linear excursion
- Paper cone
- 8 ohm
The Illuminator woofers are based on compact under-hung motor systems with large neodymium ring magnets. The patent pending motor offers a very long linear excursion together with a very high force factor. The top plate is shaped to "guide" the backside airflow around the motor and with the very open cast aluminum chassis design the driver is virtually free from compression.
- Under hung voice coil
- Neodymium magnet
- Exceptionally long linear excursion
- Paper cone
View all of the Scan-Speak Illuminator series at the Madisound Store.
Peerless 830987: 3" full range with inverted surround with aluminum cone
Peerless
full range drivers set the standard for quality audio in products
including flat panel televisions and sound bars, MP3 and cell phone
docking stations, and multimedia PCs. With their high power handling,
smooth, even dispersion and low distortion, the Peerless full range
drivers can be paired with the Tymphany LAT250 for great bass
performance.
Eton 8-200/A8 Symphony
Eton delivered several of their new Symphony line to Madisound. We will stock the rest of the Symphony line as soon as it is available.
Eton delivered several of their new Symphony line to Madisound. We will stock the rest of the Symphony line as soon as it is available.
Eton 7-200/A8 Symphony
Eton delivered several of their new Symphony line to Madisound. We will stock the rest of the Symphony line as soon as it is available.
Eton delivered several of their new Symphony line to Madisound. We will stock the rest of the Symphony line as soon as it is available.
- Bio-cellulose based hybrid cone
- UDR tangential surround / spider
- Pure magnesium center cap
- Alnico magnet (approx. 1.5kg)
- Pure iron pole piece
- Zinc alloy die-cast frame
- Silver-Copper alloy voice coil wire
- Swan folded horn design provided with driver
See pdf file for response curve, specifications, mechanical drawing and recommended box drawing.
Fountek FW168 6.5" Aluminum Cone Woofers
- Aluminum Cone
- Aluminum Phase Plug
- Die Cast Chassis
- 36mm Voice Coil Diameter
Audax TW025A28 Gold Dome Tweeters
- 25 mm gold plated dome Tweeters
- Neodymium magnet with heat sinks
- Solid aluminum face plate
- Curve 2.83 V @ 0.5 m
Peerless 830984 2.5" Full Range 8 ohm
- A Neodymium motor structure and double-venting system that helps keep
dynamic range intact, as the transducer can handle more power and
dissipate excess heat efficiently.
- An anodized aluminum dome provides
superior sound dispersion and off-axis response.
- A semi-progressive
surround reduces distortion, especially at high output through long
excursion.
- The drivers' direct connected dome dust cap (connected to
the magnet system voice coil) improves dispersion at high frequencies,
providing superior sound on the high notes.
- The inserted copper cap on the pole piece ensures control the system impedance, thereby extending the upper frequency range.
Cryo-Treated Power/IEC Plugs
Cryo-treated plugs for power cables.
 |
 |
 |
 |
 |
Designs for Audio Grade products rely on fundamental, yet superior, concepts of engineering. Highly conductive elements--silver, copper, and gold--are incorporated into high-pressure, large surface area contacts, and reduce overall resistance (which fulfills the goal of improved conductivity). Read more.
Madisound recommends using the Supra Lorad power cable with WATTGATE plugs.
Hi-Vi F1600 6" Autosound System
Kevlar/Paper composite cone with phase plug
Ferrofluid cooled fabric dome Tweeters, flush or surface
| Mid-Woofers : | CSF6 | |
| Tweeters : | BT28 | |
| Crossover : | FR600 | |
| Sensitivity : | 88dB | |
| Frequency response : | 45Hz-25KHz | |
| Max power handling : | 100W | |
| Nominal power handling : | 50W | |
| Nominal impedance : | 4Ω | |
| Installation dimensions : | Ø 157 | |
| Bore dimension : | Ø 148.5 | |
| Mounting depth : | >66 | |
| Grille dimensions : | Ø 172x22 | |
| High-pass attenuation slope : | 12dB/Octave | |
| Low-pass attenuation slope : | 12dB/Octave | |
SB Acoustics SB42FHC75-6 15" Woofers
- Cone has paper honeycomb structure with fiberglass
- Rigid cast frame with large windows
- rubber surround
- 93.5dB Efficiency
- 3" diameter voice coil
- 11.5mm peak linear excursion (x-max)
- Ventilated spider and vented pole piece
- 300 Watt power handling
Hi-Vi FR600 6" Autosound System
Kevlar/Paper composite cone with phase plug
Isodynamic ribbon Tweeters, use flush or surface mount
| Mid-Woofers : | CSF6 |
| Tweeters : | RT1.3F |
| Crossover : | FR600 |
| Sensitivity : | 88dB |
| Frequency response : | 45Hz-40KHz |
| Max power handling : | 100W |
| Nominal power handling : | 50W |
| Nominal impedance : | 4Ω |
| Installation dimensions : | Ø 157 |
| Bore dimension : | Ø 148.5 |
| Mounting depth : | >66 |
| Grille dimensions : | Ø 172x22 |
| High-pass attenuation slope : | 12dB/Octave |
| Low-pass attenuation slope : | 12dB/Octave |
SCM634 Midrange with Carbon Fiber Cone
- 4 ohm Impedance
- 3 Layer Cone: Carbon Fiber / Rohacell Foam / Carbon Fiber
- Copper sleeve on pole piece
- Uniflow aluminum die cast frame
- 3" large Hexatech Aluminum Voice Coil
- Neodymium / Ferrite Hybrid Magnet System
Tymphany LAT 250 Subwoofers
4 ohm per coil version
Drive as 4 ohm stereo, 2 ohm mono or 8 ohm mono
Only 3.5" Wide by 10-1/8" Long
The patented LAT 250 is designed to provide strong bass performance in a new vibration-free, cylindrical form factor. The driver may be configured for use in sealed, vented, bandpass or open-baffle enclosures, and provides high bass output from a very compact transducer. In typical applications, mechanical vibration is more than 90% lower than comparable loudspeakers, even at full output. The LAT 250 employs dual voice coils, and impedance configurations from 2 Ohm to 16 Ohm are available per customer requirements.
4 ohm per coil version
Drive as 4 ohm stereo, 2 ohm mono or 8 ohm mono
Only 3.5" Wide by 10-1/8" Long
The patented LAT 250 is designed to provide strong bass performance in a new vibration-free, cylindrical form factor. The driver may be configured for use in sealed, vented, bandpass or open-baffle enclosures, and provides high bass output from a very compact transducer. In typical applications, mechanical vibration is more than 90% lower than comparable loudspeakers, even at full output. The LAT 250 employs dual voice coils, and impedance configurations from 2 Ohm to 16 Ohm are available per customer requirements.
SEAS Exotic, X1-08 or X1-04, F8, 8" Full Range Driver
- 8 ohm and 4 ohm version available.
- This full range 8 inch driver has a paper cone with papyrus fibers to optimize stiffness and damping, and high frequency whizzer cone perfectly matched to the cone.
- Special foam rubber surround that reduces mass of surround by 40% compared to regular rubber surrounds, which results in higher sensitivity for the driver, and excellent damping properties.
- New GVD technology is combined with an extremely open weave spider. The threads in the weave are woven together in a way that makes the spider silent. In other words, the noise from the threads rubbing together is completely gone. The open weave is practically fully acoustically transparent and resonance problems caused by traditional spiders are reduced to a minimum.
- High temperature voice coil wound on a stiff and rigid glass fiber former. AlNiCo Magnet system in addition to a copper cap on the pole piece and an underhung voice coil reduce non linear distortion to a minimum.
Morel CAT378 Classic Advanced Series Horn Tweeters
- 94mm Horn Loading Face Plate
- Hand coated fabric dome
- Hexatech aluminum voice coil
- Replaceable dome/coil assembly
- High sensitivity (93dB)
- Gold plated terminals
Audax PR170N0 6.5" Coated Paper Cone Midrange
This is a new coated paper cone version of the popular PR170M0 midrange. We don't have the specs yet, but they are probably very similar to the PR170M0.
This is a new coated paper cone version of the popular PR170M0 midrange. We don't have the specs yet, but they are probably very similar to the PR170M0.
SEAS Prestige 27TBFC/GTV (H1213-06) Metal Dome Tweeters
- 27TBFC/GTV is a High Definition metal dome Tweeters with a wide, soft polymer surround and a shielded magnet system with a rear chamber.
- Aluminum/magnesium alloy diaphragm with pistonic behavior throughout the audible frequency range, resulting in a good dispersion also above 10kHz.
- A Hexagrid protects the diaphragm, and supports a phase plate which compensates for a slight axial roll off towards 20 kHz.
- Sonomax surround for low resonance and excellent mechanical linearity. The shielded magnet system allows use in close proximity to CRT screens.
- Using the screening can as a rear chamber with optimal acoustic damping allows the Tweeters to be used with moderately low crossover frequencies.
- Voice coil windings immersed in magnetic fluid increase short term power handling capacity and reduce the compression at high power levels.
- The chassis is precision molded from glass fiber reinforced plastic, and its front design offers optimum radiation conditions.
Peerless SDS Line 830656 5.25" Woofers
- Coated paper cone
- Rubber surround
- Aluminum voice coil
- Soft roll spider
