NOTE!

Only Audax Rear Channel Kits with Cabinets are still available.
This line is being retired, as the drivers are no longer in prodcution.

Link to Audax's Complete Instructions & Design Notes.

The Audax Home Theater System

The Audax Home Theater System was developed for Audax by Joe D'Appolito, a long time guru of the speaker industry. Once again, Joe has created a system that offers exceptional performance on a small budget. The current system consists of a Center Channel speaker, a pair of Front Channel speakers, and a pair of Rear Channel speakers. Madisound received only high praise of this system from a small poll we did several months after introduction.

The kits are based on Audax's new line of shielded Polymer Chassis woofers and Micro tweeters. The woofers feature Audax's patented Aerogel cones; light, stiff and well damped. Aerogel cones have a unique sound that is both detailed and airy. The tweeter is a 1" textile dome with a neodymium magnet system, whose compact size allows it to be placed very close to the woofers.

The Audax web page is no longer accessible. Please contact us for a hard copy of the plans to be mailed to you. These are available in advance or included with the kit at no charge.

The Madisound kits come with all the drivers, assembled crossovers with high quality parts as specified in the design, stuffing, foam, screws, all brass gold plated input terminals, gasket tape, solder and wire.

Crossover Schematics

AUDAX CENTER CHANNEL CROSSOVER

AUDAX FRONT CHANNEL CROSSOVER

AUDAX REAR CHANNEL CROSSOVER

Cabinet Schematics

Audax Center Channel Cabinet Drawing

Audax Front Channel Cabinet Drawing

Audax Rear Channel Cabinet Drawing

If purchasing the kit with cabinets, our cabinets are oak veneered MDF with solid oak corners and 1" thick front baffle. The front is black with a full black grill and the back is black. The cabinets are available in either a clear varnish over oak veneer or a black painted oak veneer. Cabinets are fully assembled and precut. If purchasing the kits without cabinets, we provide cabinet plans, but you may need to order grill cloth, grill fasteners and ports. We don't have a cabinet made for the subwoofer, but you could use our WSNHT enclosure and add a port.

Audax Center Channel

Our Cabinet Dimensions: 24" wide x 11" tall x 13 3/4" deep (including 1/2" grill)

Price with cabinet $330.00 each
Price without cabinet $180.00 each

Audax Front Channel

Our Cabinet Dimensions: 9 1/2" wide x 20 1/2" tall x 14 1/2" deep (including 1/2" grill)

Price with cabinets $560.00 / pair
Price without cabinets $260.00 / pair

Audax Rear Channel

Our Cabinet Dimensions: 9" wide x 12 1/2" tall x 9 3/4" deep (including 1/2" grill)

Price with cabinets $350.00 / pair
Price without cabinets $170.00 / pair
